Shanling SM1.3R Streamer with R2R DAC

0 Reviews Write a review
SHANSM13R

In stock

Options

As low as: £1,799.00
...or from /month on finance (read more)
Ex VAT: £1,499.17

 Brand new in original retail packaging
The Shanling SM1.3R Streamer with R2R DAC combines modern network streaming technology with the rich, natural character of a true R2R DAC design. Building on the successful SM1.3 platform, this upgraded version replaces the traditional AKM DAC section with Shanling’s own in-house developed 24-bit R2R DAC architecture.
calculator-icon
Novuna Finance Calculator
Finance available. See checkout for representative details.
View the full range

Features

Headphone Socket No
Brand Color None
Warranty The length of time your product is protected by warranty 1 Year
Product Type Other

Tech Specs

General
- Dimensions (including feet): 280 × 280 × 110 mm
- Weight: 6.4 kg
- Display: 5.8 in Sharp touchscreen (1080p)
- Processor: Rockchip ARM CPU
- DAC architecture: R2R discrete assembly
- Internal storage: 64 GB
- Expansion: M.2 SSD slot
- External drive support: Up to 2 TB
- Power supply: Region-locked 110 V or 220 V

Wireless Connectivity
- Bluetooth version: 5.2
- Supported codecs:
- LDAC
- aptX HD
- aptX Adaptive
- aptX LL
- aptX
- AAC
- SBC
- Wi-Fi: Dual-band Wi-Fi 6 (2.4 GHz / 5 GHz)

Hi-Res Audio Support
- PCM: Up to 768 kHz / 32-bit
- DSD: Up to DSD512

Supported Audio Formats
- DSD, DXD
- APE, FLAC, WAV, AIFF/AIF
- DTS, MP3, WMA, AAC, OGG
- ALAC, MP2, M4A, AC3
- OPUS, TAK
- CUE sheet support

Analogue Outputs

RCA Output
- Output level: 2.2 V
- Frequency response: 20 Hz–40 kHz (-0.5 dB)
- THD+N: 0.003 %
- Dynamic range: 118 dB
- Channel separation: 116 dB
- Signal-to-noise ratio: 118 dB

XLR Output
- Output level: 4.4 V
- Frequency response: 20 Hz–40 kHz (-0.5 dB)
- THD+N: 0.003 %
- Dynamic range: 120 dB
- Channel separation: 117 dB
- Signal-to-noise ratio: 120 dB

Headphone Output
- Output power:
- Low gain: 17 mW @ 32 ohm
- Medium gain: 159 mW @ 32 ohm
- High gain: 900 mW @ 32 ohm
- High gain: 130 mW @ 300 ohm
- Frequency response: 20 Hz–40 kHz (-0.5 dB)
- THD+N: 0.003 % @ 32 ohm
- Dynamic range: 116 dB @ 32 ohm
- Channel separation: 70 dB @ 32 ohm
- Signal-to-noise ratio: 116 dB @ 32 ohm
- Noise floor: 111 dB
- Output impedance: 4.7 ohm

Digital Inputs
- Coaxial input: PCM 192 kHz / 24-bit
- Optical input: PCM 192 kHz / 24-bit
- USB input: PCM 768 kHz / 32-bit, DSD512

Digital Outputs
- Coaxial output: PCM 192 kHz / 24-bit
- Optical output: PCM 192 kHz / 24-bit
- USB output: PCM 768 kHz / 32-bit, DSD512
- I²S output: PCM 768 kHz, DSD512

... chevron-up

Description

The Shanling SM1.3R Streamer with R2R DAC combines modern network streaming technology with the rich, natural character of a true R2R DAC design. Building on the successful SM1.3 platform, this upgraded version replaces the traditional AKM DAC section with Shanling’s own in-house developed 24-bit R2R DAC architecture.

Borrowing technology from the flagship SCD3.3 SACD player, the SM1.3R is designed to deliver a more analogue-like presentation with exceptional tonal realism, texture, and musicality.

The DAC stage uses 212 ultra-precise 0.01% resistors to ensure outstanding accuracy and low distortion. This combination of modern convenience and classic Hi-Fi sound makes the SM1.3R ideal for audiophiles who want the flexibility of streaming alongside the warmth and engagement associated with high-end analogue systems.

Premium Streaming Platform and Music Services

The Shanling SM1.3R Streamer with R2R DAC is built around a powerful closed Android streaming platform that provides smooth performance and broad compatibility with modern music services.

Designed for effortless access to both local and online libraries, the streamer supports popular platforms including Spotify, TIDAL, Qobuz, Apple Music, and Amazon Music directly from the unit itself. Full support for Roon Ready, TIDAL Connect, and Qobuz Connect ensures seamless integration into advanced streaming systems and multi-room environments.

The responsive user interface makes navigation intuitive, while support for an internal SSD slot allows users to build large local music libraries directly within the player. Whether streaming high-resolution albums from the cloud or playing locally stored files, the SM1.3R offers a refined and highly stable listening experience.

High-End Audio Engineering and Connectivity

Every aspect of the Shanling SM1.3R Streamer with R2R DAC has been engineered for serious audio performance. Its advanced internal design features a dedicated 31W split power supply that isolates sensitive audio circuitry from digital processing stages, helping to reduce interference and maintain exceptional signal purity.

The fully balanced architecture contributes to lower noise levels, improved channel separation, and greater dynamic expression. A dedicated headphone output allows the SM1.3R to function as a premium desktop listening solution without requiring additional amplification.

Extensive connectivity options make integration simple across a wide range of Hi-Fi systems, whether paired with active speakers, integrated amplifiers, external headphone amplifiers, or high-end DAC setups. The result is a highly versatile source component that performs equally well in traditional stereo systems and modern digital audio environments.

Elegant Design with Audiophile Flexibility

The Shanling SM1.3R Streamer with R2R DAC combines sophisticated engineering with premium industrial design to create a streamer worthy of any high-end audio setup. Its precision-built chassis provides excellent rigidity and shielding while maintaining a clean, minimalist appearance that complements both modern and traditional Hi-Fi systems.

The compact form factor allows easy placement within desktop systems or full-size audio racks, while the intuitive interface ensures effortless daily operation.

Shanling has focused on delivering a listening experience that feels both technologically advanced and emotionally engaging, combining the convenience of digital streaming with the smooth, organic qualities often associated with analogue playback.

For listeners seeking a streamer that offers flexibility, premium construction, and a uniquely musical presentation, the SM1.3R stands out as a compelling high-end solution for modern audiophile systems.
