PS Audio Stellar Phono Stage
In stock
Features
| MC input | No |
|---|---|
| MM Input | No |
| Adjustable Gain | No |
| Brand Color | None |
| Adjustable Impedance | No |
| Warranty The length of time your product is protected by warranty | 3 Years |
| Product Type | Other |
Tech Specs
- Unit Weight: 21.6lbs. (9.8 kg)
- Unit Dimensions: 17”W x 13”D x 3.25”H (43cm x 33.02cm x 8.255cm)
- Shipping Weight: 25.1lbs (11.4 kg)
- Shipping Dimensions: 22”W x 8”H x 17”D (55.88cm x 43.18cm x 20.32cm)
- Voltage Options: (Factory set only)
- Japan 100V
- North America: 120V
- Europe/Asia/Australia/New Zealand 230V
- Mains Power Input: IEC C14
- Idle Power Consumption: 26W
- Fuses: 100V: T250V-2.0AH (2A Slow Blow)
- 120V: T250V-1.6AH (1.6A Slow Blow)
- 230V: T250V-1AH (1A Slow Blow)
- Accessories Included: US (NEMA 5-15P) (100V/120V versions)
- Schuko: (CEE7/7) (230V version)
- UK: (BS1363) (230V version)
- Audio Inputs: RCA (Unbalanced) MM,MC
- Audio Outputs: RCA (Unbalanced) 1 Stereo Pair
- XLR (Balanced): 1 Stereo Pair
- DC Trigger: 3.5mm 12VDC (2)
- Input frequency is 1kHz.
- Gain MM: 44dB, 50dB, 56dB
- MC: 60dB, 66dB, 72dB
- Input Loading MM: 47KΩ (100pF)
- MC: 60Ω, 100Ω, 200Ω, 47KΩ, Custom 1-1KΩ
- Output Impedance: Unbalanced <200Ω
- Balanced <200Ω per leg
- Frequency Response: 20Hz - 20KHz +/- 0.25dB
- THD: 0.5V out @ 1kHz: <0.01%
- Maximum Output: @1%THD: 24VRMS
- Overload Margin: @1kHz: >22dB
- S/N Ratio: MM: >82dB A-Weighted
- MC: >74dB A-Weighted
- Interchannel Crosstalk: >74dB
- Power Consumption: 26W
Description
PS Audio Stellar Phono Stage, made for MM sand MC cartridges, is a class A preamp designed to improve your turntable set-up with incredible transparency and quality. The Stellar phono stage features a unique hand-tuned class-A circuitry and discrete FET topology for a rich and warm sound.
Engineered by Darren Myers
The Stellar Phono Stage, engineered by Darren Myers, takes a fresh look on phono amplification and uses unique methods of design, like the addition of FET semiconductors and various other technologies, to refine your vinyl playback like never before.
Revealing New Music
The result of this design reveals nuances in music that you may have been previously heard before due to the quality of the equipment. PS Audio’s Stellar Phono stage achieves a rich tonality from your records, filling the room with that high-fidelity sound that vinyl promises.
Cartridge Loading Options
PS Audio’s Stellar phono stage features a various cartridge loading options with support for both MC and MM cartridges, and two inputs for using two-tonearms so you can get the best of both. The loading and gain options can be easily adjusted with the supplied remote control.
Fully Discrete FET Design
The Stellar phono stage has a fully discrete FET design, from the input to the output, boasting exceptionally low noise and great overload capabilities. The Stellar Phono stage achieves a high-end performance without compromise no matter what type of cartridge is used, even from the punchiest of cartridges with the wildest dynamics.
Design Features
PS Audio’s other features on the Stellar Phone preamp also includes; up to 70dB of ultra low noise gain for MC cartridges as low as 0.15mv, single ended and balanced outputs, a passive RIAA curve, ultra low noise discrete pre and post voltage regulation stages and a low internal feedback for increased transparency and openness.
Customer Reviews
Darren stated he wanted listeners to be wowed on hearing the first note, well it took longer for me to form an opinion it took two full tracks to be seduced by this phono preamp. Two tracks of the eponymously named Tracy Chapman Album. The first and most impressive thing of note was the clarity to the vocals and general instrumentation, second was the darkness of the background, almost silence when the musicians stopped playing; and then the subtleties started to become apparent. The reverberations following Tracy’s voice seems to last longer, decay slower and have a much more natural decay profile than my previous, well-regarded Sonneteer Sedley, phono amp. You were always aware of these reverberations with the Sonneteer but they sounded engineered, not on the PS Audio they sounded totally natural giving a huge increase in the sense of space and the natural recording environment. This minutia of extra detail extended to the backing instruments too. Again, with the Sonneteer, they were nicely positioned in the sound stage and sounded accurate and fixed in space, however switching to the PS Audio, each instrument developed its own pocket of space around it giving the whole soundstage a holographic feel to it. The backing instruments were no longer showing depth just by reduced volume in their playing but by developing a sense of space around them which integrated perfectly with the overall presentation and the sense of space which the entire recording created itself.
Bass seemed extended too with the PS Audio, so much so that I had to check the dip switches on the back of the Sonneteer to see if the rumble filter had been switched on all the time (it hadn’t!). Not only was the bass more extended but individual notes on a fast played bass line carried their own sound signature without blending together with the note before and the one after. A similar experience with top end, cymbals seemed to shimmer more and for longer while some subtle detail like brush work on drum skin and cymbal became easier to discern and follow without necessarily disappearing into the overall mix.
Vocals, as mentioned at the beginning, were clear and precise and I was caught out a few times when I sang along in my mind only to have to stop and replay a particular track because I realised I could actually make out the lyrics which I didn’t know because they were unclear on my previous setup.
I think you get the direction of this review, but if you are looking for a negative, then so far, it is just the total reliance on the remote control to select the correct inputs and loadings if power is lost to the unit. Sonically I haven’t come across any negatives when compared to my older, but well reviewed Sonneteer Sedley, but time will tell.
As a final endorsement, and perhaps the greatest one of this review, my wife was reading her Kindle while sitting next to me on the couch as I listened to the new phono preamp. At the end of the first track of Chrisy Moore’s Ordinary Man album she put down her Kindle and said, “that new thing sounds so much better than the old one, I’ve had to reread several passages of my book because I kept getting drawn into the music.” Well I rest my case!
