Pathos Inpol Remix MkII Integrated Amplifier
In stock
Features
| XLR Inputs | No |
|---|---|
| Brand Color | None |
| Headphones Socket | No |
| Warranty The length of time your product is protected by warranty | 2 Years |
| Product Type | Other |
Tech Specs
AMPLIFIER
Type: Stereo integrated Pure class A
Technology: double INPOL
Balanced: (fully) dig Bias/gain set
Output power: 2 x 25W/38W (@8/4Ohm)
Freq response: 2Hz–150KHz ±0.5db
Input sensitivity: 470mVRMS
Input impedance: 47KOhm
Output polarity: Selectable by remote
Vol regulator: 2x Burr Brown PGA2310
THD: 0.1% @ 25W, SNR > 100dB
Gain: 31dB Unbal, 37dB Balanced
Output impedance 0.9Ω
CONNECTIONS
Analogue In: Bal XRL, 4 unbal RCA
(HiDac required for below inputs)
Digital: USB port type “B”
SPDIF: coaxial/optical
Ethernet: RJ45, 2 USB port “A”
Outputs: Pre stereo line RCA
Balanced: Pre stereo line XLR
Headphone: 6.3mm jack connector
GENERAL
Dimensions (DWH): 370 x 280 x 180mm
Weight: 13.5Kg
Description
Pathos InPol Remix MkII is a fully-balanced pure 'Class A' integrated amplifier incorporating the latest generation double-InPol circuitry.
Intelligent Control
The digital bias/gain set technology with intelligent control is entrusted to the same microprocessor which regulates the volume ensuring efficient performance of the amplifier and its ability to drive the loudspeakers.
HiDac MkII
The optional HiDac MkII adds a high performance 32-bit/384kHz internal DAC with DSD and I2S codecs and features S/PDIF and USB (type B) inputs, for better more complete enjoyment of digital music.
The HiDac MkII incorporates a web application letting you control the DAC through a PC as well as to connect a hard disk and a Wi-Fi dongle directly to the unit transforming into a music centre. This DAC fully meets the demands of music lovers who want the best from the latest digital sources controlled via smartphone or tablet.
InPol System
InPol (Inseguitore Pompa Lineare - Linear Pump Follower) is a hugely successful and multi-award winning system patented by Pathos Acoustics.
Inpol devices have an exceptional sonic personality owing to this particular circuit design - fully balanced in Class A using a single solid-state component in follower configuration, with high current gain and with voltage gain together.
Valve Amplifier
The valve amplifier strengthens the input signal voltage and InPol supplies the current to drive the loudspeakers without any further amplification. In this way the signal is entrusted to the valves and becomes a true copy of the original with all the quality, purity and harmonic content intact.
This technology allows an increase in the theoretical output in pure Class A of between 25% and 50% together with a low output impedance which is fundamental for the damping factor, and further improved by the double InPol.
Construction
The central part of the chassis is carefully finished, while the lateral heatsinks, shaped to form the Pathos logo, make a strikingly attractive statement and serve to highlight the carefully protected valves placed in the centre of the chassis.
The elegant appearance is inherited from the ClassicRemix, with its compact dimensions making this a piece of audio equipment unique in its class.
Performance
InPol Remix raises the musical listening experience to the highest level, thanks to Pathos` audio design and engineering, along with the use of highest quality components.
