Oyaide DB-510 Silver BNC Digital Cable 1.0m
In stock
Available - Usually ships within 2-3 days
Features
| Brand Color | None |
|---|---|
| Warranty The length of time your product is protected by warranty | Limited Lifetime |
| Product Type | Other |
Tech Specs
- Conductor: 5N (99.999%) Pure Silver
- Insulation: Teflon layer + Foamed Polyethylene
- Shield: Copper foil + Silver plating copper (more than 95% knitting and braiding)
- Semiconductor layer: Carbon
- Outer: UV cut polyurethane
- Impedance: 75 Ω
- Capacitance: 56.5nF/Km
- Attenuation: 23.1db/Km
- Conductor resistance: 21 Ω/Km
- Diameter (outside): 8.0mm
Description
Oyaide DB-510 Silver BNC Digital Cable in 1.0m length provides the highest levels of electrical conductivity thanks to the incorporation of pure silver.
Pure Silver Conductors
Pure silver is often seen as far superior to Oxygen Free Copper due to how good of an electrical conductor it is. Silver also offers different sound characteristics to copper as it offers more clarity, and harmonic richness. Due to it's excellent electrical conductivity, the DB-510 delivers high-speed transmissions.
