Luxman L-507Z Integrated Amplifier
In stock
Available - Usually ships within 2-3 days
Features
| XLR Inputs | No |
|---|---|
| Brand Color | None |
| Headphones Socket | No |
| Warranty The length of time your product is protected by warranty | 3 Years |
| Product Type | Other |
Tech Specs
- Rated output: 120W + 120W (8Ω), 220W + 220W (4Ω)
- Input sensitivity/input impedance: PHONO (MM): 2.5mV/47kΩ, PHONO (MC-H): 0.3mV/100Ω, PHONO (MC-L): 0.1mV/40Ω, LINE: 180mV/47kΩ, BAL.LINE: 180mV/79kΩ, MAIN IN: 1.1V/47kΩ
- Output voltage: PRE OUT: 1V
- Frequency response: PHONO: 20Hz to 20kHz (±0.5dB), LINE: 20Hz to 100kHz (within -3dB)
- Total harmonic distortion: 0.007% or less (8Ω, 1kHz), 0.03% or less (8Ω, 20Hz to 20kHz)
- S/N ratio (IHF-A): PHONO (MM): 87dB or more, PHONO (MC-H): 70dB or more, PHONO (MC-L): 62dB or more, LINE: 106dB or more
- Volume adjustment: LECUA-EX
- Amplification feedback circuit: LIFES 1.0
- Output configuration: Bipolar 4-parallel push-pull
- Damping factor: 330
- Max. amount of tone control: BASS: ±8dB at 100Hz, TREBLE: ±8dB at 760Hz, TREBLE: ±8dB at 10kHz
- Power supply: 230V~(50Hz) / 115V~(60Hz)
- Power consumption: 390W, 150W (under no signal), 0.5W (at standby)
- External dimensions: 440(W) x 193(H) x 463(D) mm, front side knob of 20mm and rear side terminal of 37mm included in depth
- Net weight: 29.4kg (main unit)
- Accessories: Remote control (RA-17A), Power cable
- Speaker terminal, Supported Y-lug terminal dimension: Width of part a: 16mm or less, Width of part b: 7mm or more
Description
The Luxman L-507Z integrated amplifier replaces both the L-590AX-II and L-507UX-II. It represents the next leap in the rich history of Luxman, featuring a brand new amplification feedback system called LIFES, opening the door to a new horizon in high end amplification.
This amplifier builds on the design of the very successful L-509X and is tuned to have a signature Luxman sound. With 110 Watts per channel into 8 ohms this amplifier has enough power to drive even the most demanding of loudspeakers.
Bringing It To LIFES
The L-507Z brings to life a brand new amplification feedback engine called LIFES (Luxman Integrated Feedback Engine System) which builds upon nearly a century of experience in delivering quality sound for the most discerning of audiophile. Using their own epoch making ODNF (Only Distortion Negative Feedback) circuitry as a base, the team at Luxman have designed what is arguably the end-game in systems.
The sound is designed to respond and feel as if it were non-feedback equipped by reducing the number of parallel elements which bringing a performance upswing unheard of in amplifiers. L-507Z packs a 3-stage Darlington triple paralleled push-pull configuration capable of delivering 110W+110W (at 8ohm) and 210W+210W (at 4ohm) meaning it certainly packs a serious punch.
Luxman Style
This unit is quintessentially Luxman, following a style and form that has given Luxman plaudits the world over for design and functionality. This unit is in a stylish white and aluminium finish, that would accentuate any home setup thanks to the clean, crisp and delicate styling cues.
Luxman Sound
The large VU meter on the L-507Z is a nod to the previous generations of Luxman amplifiers but with a genuine purpose, to allow for precise and controlled listening that will allow your speaker set to truly shine whilst the L-507Z does the leg work for you.
Also featuring is a new addition to the headphone output this time around to compliment the 6.3mm is a new 4.4mm output for those who want to experience a truly three-dimensional sound experience.
Uncompromising Quality
For L-507Z, no stone has been left unturned to produce this unit. It features some of the best circuitry, board design and materials found on the market today, giving you the confidence that the L-507Z could be your end-game amplifier and is the centerpiece of a system to be proud of.
