Ferrum Audio Wandla HP DAC Pre and Headphone Amplifier
In stock
Available - Usually ships within 2-3 days
Features
| Headphone Socket | No |
|---|---|
| Brand Color | None |
| Warranty The length of time your product is protected by warranty | 3 Years |
| Product Type | Other |
Tech Specs
Headphone section -
- THD balanced - 0.00016 % / -116 dB, 10 mW into 50 Ω;
- 0.00020 % / -114 dB, 100 mW into 50 Ω
- THD unbalanced - 0.00022 % / -113 dB, 10 mW into 50 Ω;
- 0.00022 % / -113 dB, 100 mW into 50 Ω
- Outp. Pwr SE - 1 W into 50 Ω
- Outp. Pwr Bal. - 3.5 W into 50 Ω
- Dyn. Range - 122 dB
- HP Output imp. - 0.5 Ω unbalanced
- HP Output imp. - 1 Ω balanced
- Freq. response - 3 Hz - 900 kHz
Other -
- Operation - Fully balanced, proprietary IC line amp
- DAC chip - ESS Sabre ES9038PRO
- DAC resolution - 768k/32bit, DSD 256
- Digital inputs - - AES/EBU (up to 192 kHz/24bit, DoP 64)
- Optical S/PDIF (up to 96 kHz/24bit)
- Coaxial S/PDIF (up to 192 kHz/24bit, DoP 64)
- USB-C (up to 768 kHz/32bit, DSD 256)
- ARC (up to 192 kHz/24bit), TV input with CEC
- I2S (up to 768 kHz/32bit, DSD 256), PS Audio® compatible
- MQA - decoder and renderer (on all digital inputs) with bypass mode
- Analog inputs - RCA
- Analog input Vmax - 9.5 V RMS (2 – 3.5 V RMS recommended)
- Analogue input imp - 47 kΩ
- Line outputs - balanced XLR; unbalanced RCA
- Volume control - analogue with bypass option / digital for DAC operation only
- Output level PRO - @0 dBFS, 1 kHz sine 10 V RMS balanced, 5 V RMS unbalanced
- Output level REDbook - @0 dBFS, 1 kHz sine 4 V RMS balanced, 2 V RMS unbalanced
- Frequency response -10 Hz - 200 kHz +/- 0.1 dB analog inputs
- DAC THD - -121 dB (0.00009 %); THD+N - -115 dB (unweighted)
- Analog input THD - -123 dB @ 2 V RMS output level
- Dyn. range analog - 127 dB (A-weighted)
- Dyn. range digital - 122 dB (A-weighted)
- Crosstalk - -120 dB for 1kHz, better than -100 dB for 20Hz -20kHz
- Output impedance - 22 Ω unbalanced
- Output impedance - 44 Ω balanced
- Power consumption - 13 W idle (amp off) / 18 W idle (amp on) / 35 W max.
- Power inputs - 5.5/2.5 mm DC connector centre positive
- proprietary FPL 4-pin DC connector (FPL) 22-30 VDC
- Power adapter - 100-240 VAC to 24 VDC
- Dimensions (WxDxH) - 8.6 x 8.1 x 2.0 inch / 1.7 x 20.6 x 5 cm
- Remote control - included
- Weight - 1.9 kg / 4.19 lbs
Description
The Ferrum Audio Wandla HP DAC Pre and Headphone Amplifier is the latest creation from Ferrum. It is a remarkable addition to their product lineup, bridging the gap between entry-level and flagship-level audio gear for headphone enthusiasts.
Following the success of products like HYPSOS, their revolutionary hybrid power system, the OOR flagship headphone amplifier, and the ERCO entry-level DAC, the WANDLA HP offers an elevated listening experience.
This premium DAC combines the exceptional audio qualities of Ferrum's flagship WANDLA with a powerful, fully balanced headphone amplifier, designed to satisfy those seeking more than the ERCO offers but not quite ready for the super flagship WANDLA paired with OOR.
Premium Headphone Amplifier Built-In
At its core, the WANDLA HP is essentially a WANDLA DAC paired with a high-quality headphone amplifier. The built-in headphone section offers impressive specs, including an ultra-low Total Harmonic Distortion (THD) of 0.00016% balanced and 0.00022% unbalanced, ensuring pristine sound reproduction.
With a dynamic range of 122 dB and a frequency response range from 3 Hz to 900 kHz, it delivers a superior audio experience, offering ample output power of 1 W (unbalanced) and up to 3.5 W (balanced) into 50 Ω. Whether you're driving low or high-impedance headphones, WANDLA HP ensures that your headphones will shine.
Cutting-Edge DAC Performance
The WANDLA HP is equipped with the ESS Sabre ES9038PRO DAC chip, offering 768k/32bit resolution and DSD 256 support. It supports a wide range of digital inputs including AES/EBU, USB-C, Coaxial S/PDIF, Optical S/PDIF, and I2S, delivering high-resolution audio up to 768 kHz/32bit.
Additionally, it features MQA decoding and rendering on all digital inputs, ensuring audiophile-quality streaming. The DAC operates with finely tuned digital filtering and dynamic filtering, delivering an accurate, balanced, and immersive audio experience, with dynamic range of 122 dB (digital) and 127 dB (analog).
Fully Balanced Design for Optimal Performance
The WANDLA HP is designed with fully balanced operation, making it the perfect choice for audiophiles seeking maximum clarity and separation in their music. The composite IC headphone amplifier is finely tuned for the WANDLA DAC, ensuring a seamless integration of the two components.
This design not only improves audio quality but also enhances the power output, making the WANDLA HP capable of driving demanding headphones without any loss in performance. The impressive dynamic range of 122 dB further ensures that every detail in your music is delivered with accuracy and depth.
Unleash Maximum Performance with HYPSOS
While the WANDLA HP performs beautifully out of the box, Ferrum has designed it with HYPSOS, their innovative hybrid power system, in mind. When paired with HYPSOS, the WANDLA HP reaches its full potential.
The proprietary Ferrum Power Link (FPL) connection, with 4TSD voltage sensing, allows both components to operate at their maximum, providing an unparalleled level of musicality. This combination elevates the audio experience to new heights, ensuring that you can enjoy every note with extraordinary clarity, precision, and depth.
