Emotiva BasX A3+ Three Channel Power Amplifier
In stock
Available - Usually ships within 2-3 days
Features
| Brand Color | None |
|---|---|
| Warranty The length of time your product is protected by warranty | 3 Years |
| Product Type | Other |
Tech Specs
Audio Specifications
- Power Output (ALL channels driven) - 140 watts RMS per channel; 20 Hz – 20 kHz; THD < 0.1%; into 8 Ohms - 200 watts RMS per channel; 1 kHz; THD < 1%; into 4 Ohms
- Power Output (two channels driven) - 150 watts RMS per channel; into 8 Ohms - 250 watts RMS per channel; into 4 Ohms
- Power Bandwidth (at rated power; 4 Ohm - 8 Ohm load) - 20 Hz to 20 kHz (+ / – 0.02 dB)
- Broad Band Frequency Response - 10 Hz to 80 kHz +0/-1.8 dB
- THD + noise - < 0.02% (A-weighted); ref rated power
- Signal to Noise Ratio (8 Ohm load) - > 112 dB; ref rated power; (A-weighted)
- Minimum Recommended Load Impedance (per channel) - 4 Ohms (equals one 4 Ohm load or two paralleled 8 Ohm loads)
- Damping Factor (8 Ohm load) - > 500
- Input Sensitivity (for rated power; 8 Ohm load) - 1.25
- Gain - 29 dB
- Input Impedance - 27 kOhms
Input And Output Connections
- Input Connections - Unbalanced (RCA); one each per channel - Balanced (XLR); one each per channel
- Speaker Output Connections - Audiophile grade 5-way binding posts
Trigger
- Trigger Input - 5 – 12 V (AC or DC); <10 mA input current required
- Trigger Output - 12 VDC; can drive any load up to 120 mA
Power
- 115 VAC or 230 VAC @ 50 / 60 Hz (automatically detected)
- Front Panel Controls and Indicators
- Standby - push button
- Status LEDs - one per channel; blue
- Standby LED - amber
Rear Panel Controls
- AC Power switch - rocker switch (switches AC main power)
- Status LEDs switch - disables front panel Status LEDs
Protection
- The BasX A3+ is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions.
Dimensions
- 17” wide x 4” high x 15-1/2” deep (not including connectors)
- 21-1/2” wide x 8” high x 21” deep (boxed)
Weight
- 25 lbs (unboxed)
- 31 lbs (boxed)
Description
Emotiva BasX A3+ is the latest version of this excellent three-channel power amp with a class A/B output stage that is designed to deliver a smooth, accurate and detailed audio with lots of power and natural imaging.
The BasX A3+ is built with high-class materials and is fitted with Emotiva’s very best technology to produce a outstanding performance.
Please note further info is TBC - the info below is for the prior A3 model, but expect that specs will be similar for the A3+ but improved.
The BasX Range
Emotiva’s BasX power amp range covers you for all types of hi fi set-ups, from a two-channel system through to seven-channel system. The A3 is ideal for a 3.1 channel system, whether that is upgrading the current power amp in your system or for any use where three channels is needed, particularly the front three in a surround sound system.
Powers Most Demanding Speakers
With the use of a high-class linear power supply, and an oversized toroidal power transformer, the BasX A3 is able to drive the most demanding of speakers. It delivers 140w p/ch into 8 Ohms and 200w p/ch into 4 Ohms, and is designed to sound amazing with all types of audio set-ups, no matter what style of music it is.
Fault Protection System
To prevent damage and/or unwanted noises to occur when a power shortage, the BasX A3 uses an advanced, audiophile-grade, fault protection system that protects the amp from all common faults from overloads to power cuts. It’s also entirely transparent under normal listening conditions so that you can’t hear a thing.
Various Connections
You connect the BasX A3 to almost any processor or preamp with the A3’s numerous connection types, such as the high quality, industry standard, unbalanced RCA’s, and the high grade five-way speaker terminals, which accept banana plugs, spade plugs and bare wire, perfect for most speaker types.
High Quality Build
The BasX A3 has been built with solid engineering, top class construction, expert circuitry and highly advanced technology to provide you with a reliable and consistent performance.
Stylish Look
The BasX A3 power amp is sleek and stylish with it’s minimal aesthetic and specially designed, black, aluminium, front panel, which goes with most hifi systems and home decors. It’s housed in a heavy-duty, steel chassis to help prevent resonance and to keep it’s rugged looks and style.
