Audio Technica AT-VM745xML MM Phono Cartridge
In stock
Available - Usually ships within 2-3 days
Features
| Brand Color | None |
|---|---|
| Warranty The length of time your product is protected by warranty | 2 Years |
| Product Type | Other |
Tech Specs
Type - VM
Frequency response - 20 to 27,000 Hz
Output voltage - 3.7 mV (1 kHz, 5 cm/sec.)
Channel separation - 26 dB (1 kHz)
Output balance - 1.0 dB (1 kHz)
Tracking force - 1.8 to 2.2 g (2.0 g standard)
Coil impedance - 3.2 k ohms (1 kHz)
DC resistance - 750 ohms
Recommended load impedance - 47 k ohms
Recommended load capacitance - 150 to 250 pF
Coil inductance - 480 mH (1 kHz)
Static compliance - 20 × 10-6 cm/dyne
Dynamic compliance - 7 × 10-6 cm/dyne (100 Hz)
Stylus - Stylus Nude Microlinear
Stylus curvature radius - 2.2 × 0.12 mil
Cantilever - 0.28 mm (0.011”) diameter solid boron
Vertical tracking angle - 20°
Dimensions - 29.0 mm (1.1”) × 18.3 mm (0.72”) × 17.5 mm (0.69”) (H × W × D)
Threaded hole - M2.6 × 2
Weight - 8.8 g (0.31 oz)
Description
The Audio-Technica AT-VM745xML MM Phono Cartridge is a standout in the VMx series, offering refined musical realism and an immersive soundstage. Designed to mirror the cutter head used to create master vinyl recordings, this cartridge employs a dual magnet configuration precisely aligned with the left and right stereo channels.
This enables outstanding channel separation and an extended frequency response, resulting in highly detailed and lifelike playback. The VMx series builds on the legacy of Audio-Technica’s acclaimed MM cartridges with improved materials and structural upgrades that enhance responsiveness and sensitivity to dynamic expression. Whether you're spinning jazz, classical, or rock, the AT-VM745xML delivers crisp, vibrant detail that brings your vinyl collection to life.
High-Efficiency Generator with Premium Coils
At the heart of the AT-VM745xML is a paratoroidal coil generator system that boosts efficiency and clarity. This configuration stacks two PCUHD® (Pure Copper Ultra High Drawability) coils per channel, significantly improving electromagnetic performance. The cartridge also features a central shield plate to reduce crosstalk and maintain a clean stereo image.
With fewer coil turns compared to previous models, the AT-VM745xML offers superior transient response, reproducing quick musical shifts with impressive precision. These technical advancements result in a three-dimensional, highly engaging audio experience that’s faithful to the original recording. From subtle acoustic textures to fast, dynamic passages, this cartridge excels in delivering every nuance.
Microlinear Stylus with Solid Boron Cantilever
The AT-VM745xML is equipped with a nude microlinear stylus, offering unparalleled groove tracing accuracy for intricate sound detail. Unlike elliptical or conical stylus types, the microlinear shape reduces distortion and wear while revealing subtle sonic layers. Complementing this is a premium solid boron cantilever, which is approximately 2.5 times faster at signal transmission than traditional aluminum cantilevers.
This combination enables the cartridge to accurately reproduce complex musical dynamics with minimal coloration. Housed in a die-cast aluminum body that dampens unwanted resonance, this premium model ensures stability and fidelity at every level. The result is a smooth, vibrant listening experience, especially suited for high-end audio setups.
Ease of Use and Flexible Upgrades
Built for audiophiles and hobbyists alike, the AT-VM745xML includes thoughtful features that simplify installation and enhance flexibility. Threaded inserts in the aluminum housing allow easy mounting with just two screws—no nuts needed—making it ideal for integrated tonearms. A redesigned flip-up stylus guard now includes a V-cut, serving as a visual guide to help cue the stylus accurately onto your records.
Additionally, the cartridge body is compatible with most AT-VMx series replacement styli (excluding mono models), giving users the freedom to tailor their sound or replace parts without purchasing an entirely new cartridge. With its balance of innovation, performance, and convenience, the AT-VM745xML sets a new benchmark in vinyl playback.
