Audio Technica AT-LP8x Turntable
In stock
Available - Usually ships within 2-3 days
Features
| Includes Cartridge | No |
|---|---|
| Includes Dust Cover | No |
| Brand Color | None |
| Includes USB Input | No |
| Warranty The length of time your product is protected by warranty | 2 Years |
| Product Type | Other |
Tech Specs
Turntable Specifications
- Motor - DC servo
- Drive Method - Direct drive
- Speeds - 33-1/3 RPM, 45 RPM, 78 RPM
- Turntable Platter - Die-cast aluminum, rubber damper
- Starting Torque - 1.0 Kgf.cm
- Braking System - Electronic brake
- Wow and Flutter - < 0.1% (WTD) at 3 kHz (JIS)
- Signal-to-Noise Ratio - > 60 dB
- Output Levels - PHONO: 4.0 mV nominal at 1 kHz 5cm/sec
Tonearm Specifications
- Type - Static balanced J-shaped tonearm
- Effective Length - 247 mm (9.7”)
- Overhang - 15 mm (0.59”)
- Maximum Tracking Error Angle - Less than 2.0°
- Stylus Pressure Adjustment Range - 0.0 to 4.0 g
- Applicable Cartridge Weight Range - 14.0 to 20.0 g (With subcounterweight: 17.5 to 23.5 g)
Cartridge and Headshell Specifications
- Cartridge Model - AT-VM95E BK
- Cartridge Type - VM
- Recommended Load Impedance - 47,000 ohms
- Output Voltage - 4.0 mV (1 kHz, 5 cm/sec)
- Stylus - 0.3 × 0.7 mil elliptical bonded
- Cantilever - Aluminium pipe
- Tracking Force Range - 1.8 to 2.2 g (standard 2.0 g)
- Cartridge Weight - 6.1 g (0.22 oz)
- Headshell Model - AT-LT10
- Headshell Weight - Approx. 10.7 g (0.38 oz, including lead wires)
- Headshell Overhang Adjustment - + 5.5 mm to - 2.5 mm (for AT-VM95E)
General Specifications
- Dimensions - 450 mm (18”) × 352 mm (14”) × 161 mm (6.3”) (W×D×H)
- Weight - Approx. 10.4 kg (23 lbs)
- Power Supply Requirements - 100 to 240 V, 50/60 Hz (100 V for Japan only)
- Power Consumption - 8 W
- Accessories - Dust cover, Rubber mat, Platter, Dust cover hinges, Counterweight, Subcounterweight, Headshell (AT-LT10) with VM stereo cartridge (AT-VM95E BK), 45 RPM adapter, RCA audio cable (Approx. 1.0 m / 3.3'), Power cable Approx. 1.8 m / 5.9’)
- Replacement Stylus - AT-VMN95E BK (sold separately)
- Replacement Headshell - AT-LT10 (sold separately)
Description
The Audio Technica AT-LP8 turntable is a higher end semi-automatic unit that has a newly designed tonearm that automatically lifts at the end of a record. The motor then stops. The J-shaped tonearm has a removable headshell and is pre-fitted with an AT-VM95E BK cartridge.
The diecast aluminium plater is driven by a direct drive motor and the power supply is built into the base. An RCA output is provided along with a phono lead that has an extra grounding wire. There is matching hinged dust cover.
Vintage inspired J-shaped tonearm
The J-shaped tonearm fitted to the Audio Technica AT-LP8 Turntable is inspired by the A-T models from the 1960s. Moreover, the headshell has been redesigned and comes with an AT-VM95E BK (black) cartridge with a 0.3 x 0.7 mil elliptical stylus.
This combination has excellent channel separation and low distortion. Additionally, the stylus can be upgraded with a Microlinear or Shibata type for even better performance. Lastly, you can adjust the VTA and sub-counterweight for other cartridge types.
Die-cast aluminium platter
The die-cast aluminium platter is driven by a direct drive motor and is servo controlled for accurate speed. Additionally, the platter comes with a 2.5mm rubber mat. The motor and switching power supply are mounted on the box plinth.
Two RCA output connectors are provided. The plinth is made of 16mm MDF that has good anti-resonance properties. Notably, this is a three-speed unit and will play 78 RPM records. Lastly, rubber feet are fitted that isolates the unit from vibration.
The supplied Audio Technica AT-VM95E BK cartridge
The Audio Technica AT-VM95E BK cartridge is a well-specified dual magnet unit with a frequency response of 20Hz to 20kHz. The recommended tracking weight is 2g. Moreover, there are six stylus variants. Conical, bonded elliptical, nude elliptical, Microlinear, and Shibata. There is also a larger tipped stylus for 78 RPM records.
Key Features
- Semi-automatic direct-drive turntable with three speeds: 33-1/3, 45, 78 RPM- Motor features a speed-sensor system to maintain accurate platter rotation speed
- Newly designed low-torque, direct-drive DC servo motor improves wow and flutter performance
- 25 mm rubber-damped, anti-resonance, die-cast aluminum platter with 2.5 mm rubber mat
- J-shaped tonearm with adjustable VTA (vertical tracking angle)
- Newly designed tonearm lift automatically raises the tonearm at the end of a record side and stops the motor
- AT-VM95E BK (black) cartridge (0.3 x 0.7 mil elliptical stylus) is compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application
- Newly designed lightweight AT-LT10 headshell
- Included subcounterweight provides an expanded cartridge/headshell weight range of 14.0 g – 23.5 g
- Newly designed internal switching power supply, optimized for audio performance
- MDF (medium density fiberboard) cabinet construction
- Phono-level output provides pure, direct transmission of the cartridge’s signal
- Includes detachable RCA output cable (dual RCA male to dual RCA male with ground), 45 RPM adapter, and removable hinged dust cover
