FiiO K11 Desktop DAC & Headphone Amplifier
In stock
Features
| Headphone Socket | No |
|---|---|
| Brand Color | None |
| Warranty The length of time your product is protected by warranty | 1 Year |
| Product Type | Other |
Tech Specs
Size and Weight
- Dimensions - 147mm x 133mm x 32.3mm
- Weight - 407g
General
- Main control chip (single-chip microcomputer) - GD32F303RET6
- DAC - CS43198
- Supported audio formats - 384kHz/32bit PCM, DSD256
- USB connector - Type-C
- Display type - Custom LCD
- Power supply - DC12V 2A external adapter
- SE power output 1 - L+R≥520mW +520mW (32Ω, THD+N<1%) (32Ω/single-ended/high gain)
- SE power output 2 - L+R≥60mW+60mW (300Ω, THD+N<1%) (300Ω/single-ended/high gain)
- BAL power output 1 - L+R≥1400mW+1400mW (32Ω, THD+N<1%) (32Ω/balanced/high gain)
- BAL power output 2 - L+R≥250mW+250mW (300Ω, THD+N<1%) (300Ω/ balanced/high gain)
- Frequency response - 20Hz~50kHz (Attenuation<0.2dB)
- SNR - ≥123dB (A-weighted)
- Noise floor - PO<2.8uV (A-weighted); BAL<4.9uV (A-weighted)
- Output impedance - PO<1.2Ω (32Ω load); BAL<2.4Ω (32Ω load)
- THD+N - LO<0.00035% (1kHz/10kΩ)
Description
The FiiO K11 Desktop DAC & Headphone Amplifier represents a significant advancement in audio technology, offering a multitude of features within a sleek and compact design. This amplifier is equipped with an impressive range of inputs and outputs, including USB, optical, and coaxial options, as well as 4.4mm, 6.35mm, and RCA outputs.
With its robust 1400mW power output, the K11 is designed to effortlessly drive both earphones and headphones, ensuring that users can unlock the full potential of their audio devices. The K11's thoughtful engineering and high-quality components make it an excellent choice for audiophiles seeking a versatile desktop solution that doesn’t compromise on performance.
Unmatched Power and Performance
The K11 boasts an exceptional power output of 1400mW at 32Ω, enabling it to drive a wide variety of headphones with ease. This capability ensures that even the most demanding HiFi earphones and headphones can perform at their best.
Additionally, the amplifier features three gain levels and three distinct volume curves, allowing users to tailor their listening experience based on the type of headphones they’re using.
Whether you're connecting sensitive in-ear monitors or more demanding over-ear models, the K11 ensures optimal sound quality and performance, making it an invaluable tool for both casual listeners and serious audiophiles alike.
Innovative Audio Circuitry
Within the K11 lies a specially designed audio circuit that prioritizes sound quality and reliability. It utilizes over 16 low-noise LDOs for precise voltage stabilization, which, in conjunction with an external 12V power supply, provides a clean and robust power source.
This innovative power management results in high-quality audio output that is both stable and enjoyable. The amplifier’s design minimizes noise interference, ensuring that every note is rendered with clarity. This attention to detail in the circuitry guarantees that the K11 delivers an impressive audio experience, perfect for a wide range of listening scenarios.
Elegant Design and Custom Display
The K11 features a slim aluminum alloy body that seamlessly integrates into any desktop setup, making it an aesthetically pleasing addition to your workspace. Its compact design is complemented by a custom high-contrast LCD screen that displays essential information such as sampling rate, volume, and output mode.
This durable display is always on and resistant to burn-in, ensuring you can quickly check your settings at a glance. Moreover, the adjustable RGB logo lighting adds a personalized touch, allowing users to customize the brightness and color to match their preferences and create a visually appealing audio environment.
Simplified User Experience
Designed for ease of use, the K11 incorporates a multi-function volume knob that serves as the primary control interface. This knob allows for power on/off, volume adjustment, and quick access to various settings. Users can effortlessly switch between low output (LO) and high output (PO) modes with a simple double-press, retaining the last volume settings for each mode independently.
Additionally, the K11 operates in a USB DAC driver-free mode, making it compatible with Windows 10 and above, as well as popular gaming consoles like the PS5 and Nintendo Switch. This plug-and-play functionality ensures a hassle-free audio experience, whether you’re enjoying music or gaming.
Aesthetic Choices and Comprehensive Package
Available in two elegant colors—Obsidian Black and Midnight Silver—the K11 adds a touch of sophistication to any setup. The understated charm of Obsidian Black pairs beautifully with its sleek design, while the radiance of Midnight Silver provides a stylish option for those seeking something more eye-catching.
Each K11 comes with a complete package, including a power adapter, USB cable, 6.35mm adapter, and a quick start guide, ensuring that you have everything you need to get started. This comprehensive offering makes the FiiO K11 Desktop DAC & Headphone Amplifier not just a functional audio device, but also a stylish and complete solution for your desktop audio needs.
